Electric Stacker

RSC122

Nationwide After-Sales Support

Technical Specifications

Model

RSC122

Type

Electric Counterbalance Stacker

Load capacity

1200 kg

Drive

Electric (AC)

Operator type

Pedestrian

Dimensions (L/W/H)

2668/900/3908 mm

Fork dimensions (s×e×l)

35×100×1070 mm

Lift height

3000 mm

Travel speed, laden/unladen

5.5/6 km/h

Turning radius

1250 mm

Max. gradeability, laden/unladen

5/8%

Battery voltage/nominal capacity

24V/210Ah

Service weight

1890 kg

Drive motor rating (S2 60 min)

1.6 kW

Recognition

CE Certified

Description product

Description product
More capacity with added mast convenience. The iMOW RSC122 is a 1200kg electric counterbalance stacker offering sensitive mast tilting as standard, giving operators more convenience when stacking pallets compared to regular stackers.

1200kg Electric Counterbalance Stacker

Higher Capacity, Smarter Mast Control

Alongside the standard proportional lifting system, the RSC122 offers sensitive mast tilting as standard, delivering more convenience to pallet stacking than regular stackers. A high ground clearance of 116mm supports smooth travel on uneven surfaces, and despite the higher capacity, the stacker retains a compact turning radius for confident maneuvering in confined aisles.

Why the RSC122?

Higher load capacity — 1200kg capacity for handling heavier pallets, boxes, and cages.

Sensitive mast tilting — Standard feature that adds convenience to pallet stacking compared to regular stackers.

Proportional lifting system — Standard precision lifting for gentle stacking and retrieval in multi-level racking.

High ground clearance — 116mm clearance for smooth travel on uneven surfaces.

Compact maneuverability — 1510mm turning radius for confident handling in confined warehouse areas.

Ideal Applications

Suited for warehouses needing higher-capacity pallet handling (up to 1200kg) with added mast tilting convenience, in confined or narrow-aisle environments.
